TRADE NAME | PURITY | PARTICLE SIZE | A. D. (g/cm3) | T. D. (g/cm3) | OXYGEN | MORPHOLOGY |
---|---|---|---|---|---|---|
ECP | 99.7%MIN | <45 MICRONS | 1.0-1.4 | 1.5-1.7 | <0.5% | DENTRITIC |
RCP | 99.5% MIN | <45 MICRONS | 1.8-2.2 | 2.8-3.2 | <0.4% | IRREGULAR |
ACP | 99.5% MIN | <45 MICRONS | 2.8-3.2 | 4.1-4.4 | <0.4% | IRREGULAR |
NCP | 99.5%MIN | <1 MICRONS | 0.6-0.8 | 0.9-1.1 | <0.6% | FLAKY |
Copper powder is a very dense and typically spherical metal powder that is used in the elcectronics industry due to its conductive properties.
Copper Powders are produced mainly through Electrolysis(ECP), Atomization(ACP) and Reduction(RCP) Process, further it is milled to Nano Scale(NCP).
Copper powder has many uses in powder metallurgy, including:
Other uses of copper powder include:
Copper | Values |
---|---|
Molecular Weight | 63.55 |
Appearance | Reddish metal in various forms |
Melting Point | 1085 °C |
Boiling Point | 2562 °C |
Density | 8.96 g/cm3 |
Solubility in H2O | N/A |
Electrical Resistivity | 0.39 kJ/kg·K |
Electronegativity | 1.90 Paulings |
Heat of Fusion | 13.26 kJ ·mol-1 |
Heat of Vaporization | 300.4 kJ ·mol-1 |
Poisson's Ratio | 0.34 |
Specific Heat | 0.39 kJ/kg K |
Thermal Conductivity | 1.68 x 10-8 &Ohm;·m |
Thermal Expansion | 16.5 µm·m-1·K-1 (25 °C) |
Vickers Hardness | 369 MPa |
Young's Modulus | 110-128 GPa |
